Chapter 7 Internal Access 7-5
FIGURE 7-4 Replacing the Cover
3. Replace the lock block on the rear panel. Tighten the Phillips screw that secures
the lock block to the cover.
See
FIGURE 7-5.
4. Tighten the captive Phillips screw in the upper-right corner of the rear panel.
See
FIGURE 7-5.
Caution – Do not use a power driver to tighten captive screws. Do not overtighten
captive screws.
Guide cover hinge hooks
into corresponding slots
in front of system chassis.
