Sun Microsystems SPARCstation 5 Model 110 - FIGURE 9-20 Removing the System Board

Chapter 9 Storage Devices 9-21
FIGURE 9-20 Removing the System Board
7. Remove the CD-ROM drive (if present).
See Section 9.2.1 “Removing the CD-ROM Drive.”
8. Disconnect the DC power harness from the diskette drive.
9. Free the SCSI data cable from the metal cable clips on the chassis wall and from
the card guide plastic cable clips.
See
FIGURE 9-21.
10. Disconnect the SCSI data cable from the SCSI backplane.
See
FIGURE 9-21.
11. Work the DC power harness (labeled P3) free from the card guide clips and
disconnect it from the SCSI backplane.
See
FIGURE 9-21.
Card guide
System board
