Chapter 11 System Board and Component Replacement 11-21
FIGURE 11-21 Installing the System Board
2. Tighten the two captive Phillips screws that secure the board to the rear of the
chassis.
See
FIGURE 11-22. Do not overtighten these screws.
FIGURE 11-22 System Board Captive Screws
3. Reconnect the DC power, SCSI data, diskette data, speaker/LED, and CD-ROM
audio cables to the system board.
See
FIGURE 11-18.
4. Take the following components that you removed from the defective system board
and install them on the new system board:
Card guide
System board
Captive screw
Captive screw
