Illustrated Parts Breakdown 12-5
12
12.2 Replacement Parts List
Table 12-1 provides the part numbers for customer-replaceable units. Table 12-2
provides part numbers for miscellaneous items.
Note – Although the part numbers are correct as of the publication date of this
document, they are subject to change. Consult your authorized Sun sales
representative or service provider to confirm part numbers before you order
new or replacement parts.
Table 12-1 Part Number List—Customer-Replaceable Units
Item Description Sun Part No.
1 8-Mbyte DSIMM Module 501-2470
2 32-Mbyte DSIMM Module 501-2471
3 NVRAM/TOD 525-1369
4 Main Logic Board (0 Mbyte, 70 MHz) 501-2798
5 Main Logic Board (0 Mbyte, 85 MHz) 501-2799
6 Main Logic Board (0 Mbyte, 85 MHz) 501-2815
7 Main Logic Board (0 Mbyte, 110 MHz) 501-2778
8 Main Logic Board (0 Mbyte, 170 MHz) 501-3059
9 535-Mbyte Internal Disk Drive 540-2443
10 1.05-Gbyte Internal Disk Drive 540-2560
11 2-Gbyte Internal Disk Drive 540-2699
12 Internal CD-ROM Drive 540-2852
13 3.5-inch Internal Diskette Drive 540-2854
14 150-Watt Power supply 300-1215
15 Internal Speaker Assembly 370-1579
16 SCSI Backplane 501-2462
17 CD-ROM Audio Cable (Internal) 530-2280
18 Diskette Drive Cable (Internal) 530-2277
19 Speaker/LED Cable (Internal) 530-2341
