A-2 SPARCstation 5 Service Manual—November 1996
A
A.1 Physical Specifications
Table A-1 lists the physical specifications for the system unit, keyboard, and
optical mouse.
A.2 Input Power Requirements
Table A-2 lists the input power requirements for the system unit.
*Maximum input current with accessory connected to accessory outlet is 6 A.
Table A-1 Physical Specifications
Component
Height
inches (mm)
Width
inches (mm)
Depth
inches (mm)
Net Weight
lbs (kg)
System Unit 3.07 (78) 16.40 (417) 16.10 (409) 27.0 (12.7)
Keyboard 1.7 (44) 20.1 (510) 7.2 (182) 3.5 (1.6)
Mouse 2.0 (50) 4.0 (100) 3.0 (80) 0.3 (0.14)
Table A-2 Input Power Requirements and Power Dissipation
Parameter Specification
Nominal Frequencies 50 Hz or 60 Hz nominal
Nominal Voltage Range 100-120 Vac or 200-240 Vac
(100-240 Vac Auto)
Maximum Current AC RMS* 2 A @ 100-120 Vac, 1 A @ 200-240 Vac
AC Operating Range 87-264 Vrms, 47-63 Hz
Maximum VA Rating 200 VA
Maximum Power Consumption 200 Watts
Maximum Heat Output 683 BTU/hr
