Index-1
Index
A
AC power cord, illustration, 12-3
access, to subassemblies, 7-1
antistatic
precautions, 5-4, 10-2
wrist strap, attaching, 7-4
attachment unit interface
See AUI
audio connector pinouts, B-8
AUI connector pinout, B-4
AUI Ethernet adapter cable, 12-4
auto-boot? parameter, 2-4 to 2-6, 2-10,
3-5
B
boot <disk alias> command, 2-8
boot failure, 4-2
boot-dev parameter, 2-5
boot-file parameter, 2-5
C
cables, illustrations, 12-3, 12-4
CD-ROM audio cable, 9-29
removal/replacement, 9-29 to 9-31
CD-ROM drive, 9-7
removal/replacement, 9-7 to 9-9
Centronics parallel printer cable, 12-4
connector pin assignments
audio connectors, B-8
AUI connector, B-4
keyboard/mouse connector, B-7
parallel connector, B-3
SCSI connector, B-2
serial connectors, B-6
twisted-pair Ethernet connector, B-5
video connector, B-10
CPU board
See system board
CRU
illustrations, 12-2
locating defective, 2-11
replacement part numbers, 12-5
tools for removal/replacement, 5-4
customer-replaceable unit
See CRU
D
DC power harness, 9-21
removal/replacement, 9-21 to 9-27
diag-device parameter, 2-5
diag-file parameter, 2-5
Diagnostic Executive, 2-11
diagnostics
default boot mode, 2-2
