Index-2 SPARCstation 5 Model 110 Service Manual • November 1996
diskette drive, 9-8
removal/replacement, 9-8 to 9-13
DSIMM, 11-13
locating faulty, 4-7
removal/replacement, 11-13 to 11-17
See also memory
E
electrostatic discharge precautions, 5-4
environmental requirements, A-2
error messages, 3-8
disk drive, 4-6
read, write, or parity, 4-2, 4-6
external options, 1-5
F
FORTH Toolkit, 2-7
H
hung system, 6-2
halting, 6-2
I
illustrated parts breakdown, 12-1 to 12-5
input power requirements, A-2
interior view of system, 1-2
internal options, 1-4
K
keyboard diagnostic LEDs, 3-2, 3-9
keyboard/mouse connector pinout, B-6
M
main logic board
See system board
memory
address ranges, 4-8
arrangement of slots, 4-7
error reporting, 4-7
location "J" number, 4-7
physical address, 4-7
See also DSIMM
mfg-switch? parameter, 2-4
microphone illustration, 12-3
module-info, D-7
N
nonvolatile random access memory
See NVRAM
NVRAM
parameters, 2-4
removal/replacement, 11-24 to 11-25
O
ok prompt, 2-4 to 2-7, 2-11
On-Board Diagnostics, D-1
options
external, 1-5
internal, 1-4
P
parallel connector pinout, B-2
part numbers, listing, 12-4
physical specifications, A-1
pin assignments
See connector pin assignments
POST, 3-1, 3-8
detailed information, 3-4
Diagnostic Mode, 3-4
full diagnostic tests, 3-6
keyboard LEDs, 3-2, 3-3
Normal Mode, 3-4
overview, 2-3
silent (abbreviated), 3-5
system failures, 3-3
system passes, 3-4
power
turning off, 6-1 to 6-3
turning on, 6-4
power LED, 8-5
removal/replacement, 8-5 to 8-8
