5-10 Sun Fire T2000 Server Service Manual • July 2007
FIGURE 5-6 Location of PCI-Express and PCI-X Card Slots
4. Note and remove any cables that are attached to the card.
5. Rotate the PCI hold-down bracket 90 degrees so it no longer covers the PCI card
(
FIGURE 5-7).
PCI-E slots 0, 1, 2
PCI-X slots 0, 1
