5-28 Sun Fire T2000 Server Service Manual • July 2007
FIGURE 5-17 Location of Power Supply Latch
3. Disconnect all cables from the PDB:
■ Disconnect the hard drive power connector from the PDB.
■ Release the latches on the DVD cable and disconnect it.
■ Disconnect the cable marked P7.
■ Disconnect the blower power cable from the power distribution board.
Power supply latches
