5-24 Sun Fire T2000 Server Service Manual • July 2007
Caution – A flexible cable connects the CPU and I/O boards. This flexible cable is
fragile. Handle these parts very carefully to prevent damage.
Caution – This procedure requires that you handle components that are sensitive to
static discharges that can cause the component to fail. To avoid this problem, ensure
that you follow antistatic practices as described in Section 5.1.6, “Performing
Electrostatic Discharge Prevention Measures” on page 5-6.
1. Unpackage the replacement motherboard assembly and place it on an antistatic
mat.
2. Tilt the motherboard assembly over the interior wall into the chassis (
FIGURE 5-15)
and place it down on the rear standoffs
Avoid touching the front standoffs with the motherboard.
3. Slide the motherboard backward on the rear standoffs to engage the connectors in
the rear cutouts.
4. Place the front of the motherboard down on the front standoffs.
The front of the motherboard refers to the part of the motherboard nearest the front
of the server.
