A-6 Sun Fire T2000 Server Service Manual • July 2007
14 SAS disk
backplane
Section 5.2.19,
“Removing the SAS
Disk Backplane” on
page 5-37
The SAS backplane board contains the Molex
connector for interfacing to 2.5 SAS or S-ATA disk
drives. In addition, the board contains four
seven-position vertical SAS connectors that bring
each of the four SAS links from the I/O board.
This board contains the electronic chassis serial
number.
SASBP
15 Hard drives Section 4.5.1,
“Removing a Hard
Drive” on page 4-9
SFF SAS, 2.5-inch form-factor hard drives. HDD0
HDD1
HDD2
HDD3
16 DVD drive Section 5.2.17,
“Removing the
DVD Drive” on
page 5-37
DVD/CD-ROM drive. DVD
* The FRU name is used in system messages.
TABLE A-1
Server FRU List (Continued)
Item No. FRU
Replacement
Instructions Description FRU Name
*
