2-122 SPARC Enterprise Mx000 Servers XSCF User’s Guide • August 2009
2.2.12 System Board Configuration
System board configuration settings are used to specify XSB division information for
a PSB and configure the memory mirror mode.
System board configuration is a function which is available on the
M4000/M5000/M8000/M9000 servers. In the M3000 server, the system board has
been configured by default and you cannot change the settings. However, you can
refer to the system board information
Before dividing a PSB into XSBs or changing the memory mirror mode, make sure
that the PSB is not assigned to any domain (system board pool state; unassign).
TABLE 2-25 lists a term used in system board configuration.
TABLE 2-26 lists the settings and the corresponding shell commands.
TABLE 2-25 System Board Configuration Term
Term Description
Memory mirror
mode
In this mode, a PSB has two memory units, one mirroring the other. Saving the same data in
the separate memory units improves data security.
TABLE 2-26 System Board Configuration
Item Description Shell Command Remarks
Display XSB
division/
memory
mirror mode
information
Displays information on dividing a PSB into XSBs and
memory mirror mode information.
showfru
XSB division Sets one of the following PSB type:
• Divide as one unit (not divided) (Uni-XSB).
• Divide as four units (Quad-XSB).
setupfru
Memory
mirror mode
Enables or disables the memory mirroring.
• Enable (mirroring).
• Disable (mirroring).
Mirroring
is disabled
by default.
(Note 1)
Add device The device, such as a system board, is added. addfru (Note 2)
