Chapter 1 XSCF Overview 1-19
FIGURE 1-6 Two XSCF-LANs and Two XSCF Units Configuration (In High-End Servers)
For details on LAN configurations and connections, see Chapter 3. For details on
specifying IP addresses, see Chapter 2.
Active
XSCF
Standby
XSCF
System
Failure of a path
c) A subnet failed
Active
XSCF
Standby
XSCF
System
XSCF failed
d) XSCF failed
Failover
