Chapter 2 Setting Up XSCF 2-13
■ Specify the host name or the IP address of the XSCF during the network
configuration, in a web browser running on a PC with an XSCF-LAN port used to
establish a connection to the XSCF.
(This screen image is an example and differs from the actual screen display.)
Note – The web browser window for the XSCF Web is called the XSCF Web console.
■ Log in.
(This screen image is an example and differs from the actual screen display.)
Note – When connecting using https, a warning message appears in the web
browser until the certificate is installed.
11. Open the XSCF Administration window.
(This screen image is an example and differs from the actual screen display.)
■ The remaining setting items are the same as those applicable to setup using the
XSCF Web. Referring to the setup flow, proceed to Step 9 and later steps in
Section 2.1.1, “Setup Summary by the XSCF Shell” on page 2-3. For details on the
commands used to make settings, see the corresponding parts of Section 2.2,
“Specifying the XSCF Settings” on page 2-14.
<Web browser screen image>
URL https://192.168.111.111/ (The IP address of XSCF is input by number)
Alternatively:
https://XSCF-host-name/ (Not the host name of a domain)
<Web browser screen image>
login:yyyy
Password:xxxxxxxx
<Web browser screen image>
XSCF Web console
- Remote Maintenance Service Administration
- Firmware Update
To Next Page
