3-58 ENGINE
OIL SEAL REASSEMBLY
• Apply grease to the oil seal lip.
W 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
• Install the oil seal with the special tool.
[ 09913-70210: Bearing installer set
BUSHING INSTALLATION
•
Replace the bushing with a new one if necessary.
• Assemble the engine mount bushing as shown in the illustra-
tion.
Use a new Oil seal.
Bushing
Crankcase
0.5 mm (0.0197 in)
