20-34 SERVICING INFORMATION

FUEL TANK CUSHION INSTALLATION

*1

1 Fuel tank rear cushion 5 Frame

2 Spacer 6 Fuel tank side cushion

3 Fuel tank front cushion a 213 mm (8.39 in)

4 Fuel tank *1 Clean an adhesive surface before adhering the cushion.
