Sysmac CQM1 User Manual

!
3-6SectionProgramming Console Operations
100
4. Press the CLR Key to end 3-word monitoring and return to the normal moni-
toring display. The rightmost word on the 3-word monitor display will be
monitored.
CLR
D0002
0123
Note Just one word will be monitored, even if 2 or more words were dis-
played when 3-word monitoring was initiated.
3-6-17 Decimal Monitor With Sign
With this operation, hexadecimal data in a word is regarded as hexadecimal
expressed by two’s complement, and is converted to decimal with sign for
display. In addition, two consecutive words of data can be displayed in deci-
mal as eight digits of hexadecimal (double-length display). I/O monitoring,
multiple address monitoring, and 3-word data modification can be used dur-
ing execution.
Caution This function cannot be used with CQM1-CPU11-E and CQM1-CPU21-E CPU
Units.
Note In PROGRAM or MONITOR mode, it is possible to change word data by means
of a decimal-with-sign input. Refer to
3-6-23 Decimal Data Modification (With
Sign)
.
RUN MONITOR PROGRAM
OK OK OK
1, 2, 3... 1. Monitor the word that is to be used for decimal monitor with sign. During mul-
tiple address monitoring, the word on the left is the object.
Multiple address monitoring
cL01 cL0200001
FFF0 F000^ OFF
2. Decimal monitor with sign is executed. When the SHIFT and TR keys are
pressed here, I/O monitor, multiple address monitoring, or 3-word data mod-
ification is restored.
SHIFT TR
cL01
-00016
• Double-length Display
3. The word that was monitored is taken as the rightmost four digits of eight
digits hexadecimal, and the next word as the leftmost four digits, and they
are converted to a decimal number with sign for display.
EXT
cL02 cL01
-0268369936
4. When the decimal monitoring with sign has been completed, I/O monitor,
multiple address monitoring, or 3-word data modification is restored.
SHIFT TR
cL01 cL0200001
FFF0 F000^ OFF
Note I/O monitor, multiple address monitoring, or 3-word data modification can also
be restored by means of the CLR Key.
