19
The following table shows the current consumption of the CPU Unit and I/O
Units:
Unit Model Number Current Consumption (5 VDC)
CPU Units
CQM1-CPU11-E 800 mA
CQM1-CPU21-E 820 mA
CQM1-CPU41-EV1 820 mA
CQM1-CPU42-EV1 820 mA
CQM1-CPU43-EV1 980 mA
CQM1-CPU44-EV1 980 mA
DC Input Units
CQM1-ID111 85 mA
CQM1-ID112 170 mA
CQM1-ID211 50 mA
CQM1-ID212 85 mA
CQM1-ID213 170 mA
CQM1-ID214 170 mA
AC Input Units CQM1-IA121/221 50 mA
Contact Output Units
CQM1-OC221 430 mA
CQM1-OC222 850 mA
CQM1-OC224 440 mA
Transistor Output Units
CQM1-OD211 90 mA
CQM1-OD212 170 mA
CQM1-OD213 240 mA
CQM1-OD214 170 mA
CQM1-OD215 110 mA
CQM1-OD216 240 mA
Triac Output Unit
CQM1-OA221 110 mA
CQM1-OA222 250 mA
B7A Interface Units CQM1-B7Ajj 100 mA
I/O Link Unit CQM1-LK501 150 mA
Analog Input Unit CQM1-AD041 80 mA
Analog Output Unit CQM1-DA021 90 mA
Power Supply Units
CQM1-IPS01 420 mA
CQM1-LSE01 380 mA
Unit
CQM1-LSE02 450 mA
Temperature Control Units
CQM1-TC00j/10j 220 mA
CQM1-TC20j/30j 190 mA
G730 Interface Units
CQM1-G7M21
(Master)
250 mA
CQM1-G7N11/01
Expansion Master
80 mA
CompoBus Units
CQM1-SRM21 180 mA
CQM1-DRT21 80 mA
The total current consumption of the components in a PC must be less than the
capacity of the Power Supply Unit being used. For example, a CQM1-PA203
Power Supply Unit (capacity: 3.6 A) can be used with a CQM1-CPU21-E CPU
Unit, two 16-point DC Input Units, and three 16-point Contact Output Units, as
shown below:
Current Consumption = 0.82 + (0.085 × 2) + (0.85 × 3) = 3.54 A ≤ 3.6 A
Current Consumption of
Components
Power Supply Unit
Section 2-2
