Sysmac CQM1 User Manual

58
2-6-9 AC Input Units
Item CQM1-IA121 CQM1-IA221
Input Voltage 100 to 120 VAC
+10%
/
–15%,
, 50/60 Hz 200 to 240 VAC
+10%
/
–15%,
, 50/60 Hz
Input
Impedance
20 kΩ (50 Hz), 17 kΩ (60 Hz) 38 kΩ (50 Hz), 32 kΩ (60 Hz)
Input Current 5 mA typical (at 100 VAC) 6 mA typical (at 200 VAC)
ON Voltage 60 VAC min. 150 VAC min.
OFF Voltage 20 VAC max. 40 VAC max.
ON Delay 35 ms max. 35 ms max.
OFF Delay 55 ms max. 55 ms max.
No. of Inputs 8 points (8 points/common, 1 circuit) 8 points (8 points/common, 1 circuit)
Internal Current
Consumption
50 mA max. at 5 VDC 50 mA max. at 5 VDC
Weight 210 grams max. 210 grams max.
Circuit
Configuration
COM
470 Ω
Input
LED
Internal
Circuits
2.7 kΩ
0.15 µF
IN
IN
68 kΩ
COM
820 Ω
Input
LED
Internal
Circuits
8.2 kΩ
0.082 µF
IN
IN
220 kΩ
Terminal
Connections
B0
0
1
A0
B1
2
3
A1
B2
4
5
A2
B3
6
7
B4
A4
B5
A5
B6
A6
B7
A7
B8
A8
A3
COM
NC
NC
NC
NC
NC
NC
NC
NC
COM
100 to 120 VAC
B0
0
1
A0
B1
2
3
A1
B2
4
5
A2
B3
6
7
B4
A4
B5
A5
B6
A6
B7
A7
B8
A8
A3
COM
NC
NC
NC
NC
NC
NC
NC
NC
COM
200 to 240 VAC
Unit Specifications
Section 2-6

Sysmac CQM1 Specifications

General

Manufacturer	Omron
Operating Temperature	0 to 55°C
Humidity	10 to 90% RH (non-condensing)
Power Supply	100 to 240 VAC or 24 VDC (depending on model)
Programming Language	Ladder Diagram, Instruction List
Communication Ports	RS-232C
Expansion	Expansion I/O units available
Analog I/O	Available via expansion units
Instruction Set	Basic and advanced instructions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
