Appendix AStandard Models
127
Name SpecificationsModel number
Remote Console CQM1-TU001 The Remote Console is connected to a Sensor Unit for the adjustment of
the sensitivities of the modules incorporated by the Sensor Unit, reading
and changing of the set value, and teaching.
Cable length: 3 m
G730 Interface Units
CQM1-G7M21 Master: 32 inputs and 32 outputs
CQM1-G7N01 Expansion Master: 32 outputs
CQM1-G7N11 Expansion Master: 32 inputs
Temperature Control
CQM1-TC001 Thermocouple input, transistor (NPN) output, 2 loops
Units
CQM1-TC002 Thermocouple input, transistor (PNP) output, 2 loops
CQM1-TC101 Platinum resistance thermometer, transistor (NPN) output, 2 loops
CQM1-TC102 Platinum resistance thermometer, transistor (PNP) output, 2 loops
CompoBus/S
Master Unit
CQM1-SRM21 128 points (64 inputs and 64 outputs); 64 points (32 inputs and 32
outputs); 32 points (16 inputs and 16 outputs)
Switchable
CompoBus/D (DeviceNet)
I/O Link Unit
CQM1-DRT21 16 inputs and 16 outputs (total: 32 points)
DIN Track and Accessories
Name Model number Specifications
DIN Track
PFP-50N Track length: 50 cm; track height: 7.3 cm
PFP-100N Track length: 100 cm; track height: 7.3 cm
DIN Track Brackets PFP-M Two required for each PC mounted to DIN Track.
Peripheral Devices
Name Model number Specifications
Programming Console
CQM1-PRO01-E 2-m Connecting Cable attached
C200H-PRO27-E Hand-held, w/backlight; requires the C200H-CN222 or
C200H-CN422, see below
Ladder Support Software
C500-SF312-EV3 3.5”, 2HD for IBM PC/AT compatible
(see note)
C500-SF711-EV3 5.25”, 2D for IBM PC/AT compatible
SYSMAC Support Software C500-ZL3AT1-E 3.5”, 2HD for IBM PC/AT compatible
Connecting Cable
CQM1-CIF02 Connects IBM PC/AT or compatible computers to Peripheral Port
C200H-CN222 Connects C200H Programming Console to Peripheral Port (2 m)
C200H-CN422 Connects C200H Programming Console to Peripheral Port (4 m)
Note Use Version-3 LSS or a later version for CQM1 operation.
Memory Cassettes (Optional)
Model number Clock function Memory
CQM1-ME04K No
4K-word EEPROM
CQM1-ME04R Yes
CQM1-ME08K No
8K-word EEPROM
CQM1-ME08R Yes
CQM1-MP08K No
EPROM IC socket only. EPROM chip not included. Refer to the following
table for details on available EPROM ICs.
EPROM ICs
Model number EPROM version Capacity Access speed
ROM-ID-B 27128 16K bytes 150 ns
ROM-JD-B 27256 32K bytes 150 ns
ROM-KD-B 27512 64K bytes 150 ns
