6Conformance to EC Directives
xiv
When switching a load with a high inrush current, such as an incandescent lamp,
suppress the inrush current as shown below.
OUT
COM
R
OUT
COM
R
Countermeasure 1
Providing a dark current of approx.
one-third of the rated value
through an incandescent lamp
Countermeasure 2
Providing a limiting resistor
