2-1 CPU Unit
The CQM1 is a compact, high-speed PC made up of a CPU Unit, Power Supply
Unit, and I/O Units that together provide up to 256 total I/O points. These compo-
nents lock together at the sides, allowing simple changes in the size and capac-
ity of the PC. There are six types of CPU Unit, shown in the table below. All of the
CPU Units except for the CQM1-CPU11-E have a built-in RS-232C interface.
Model Maximum
I/O points
Program
capacity
(words)
DM
capacity
(Words)
RS-232C
port
Analog
setting
Pulse
I/O
ABS
interface
AD/DA
conver-
sion
CQM1-CPU11-E
128 pts
(7 Units
3.2K 1K
--- --- --- --- ---
CQM1-CPU21-E
(7
U
n
it
s
max.)
Yes
--- --- --- ---
CQM1-CPU41-EV1
256 pts
(11 U i
7.2K 6K
--- --- --- ---
CQM1-CPU42-EV1
(11 Units
max )
Yes --- --- ---
CQM1-CPU43-EV1
max.
)
--- Yes --- ---
CQM1-CPU44-EV1 --- --- Yes ---
CQM1-CPU11-E and CQM1-CPU21-E CPU Units provide a maximum of 128
I/O points. The only difference between the two models is the RS-232C port
that is added to the CQM1-CPU21-E.
The CQM1-CPU42-EV1 CPU Unit provides a built-in analog setting function.
It has four dedicated volume controls, and their respective values (0 to 200
BCD) appear in words 220 to 223. This function can be used for operations
such as changing timer and counter set values during operation.
The CQM1-CPU43-EV1 CPU Unit provides a built-in pulse input and output
function. It has two dedicated ports for high-speed counting of up to 25-kHz
two-phase pulse inputs from a device such as a rotary encoder and output-
ting up to 50-kHz pulses to a device such as a stepping motor.
The CQM1-CPU44-EV1 has two ABS interfaces (absolute encoder inter-
faces) that can directly receive inputs from absolute-type rotary encoders.
Note In this manual, CQM1-CPU11-E/21-E CPU Units are referred to as “standard
CPU Units,” and CQM1-CPU41-EV1/42-EV1/43-EV1/44-EV1 CPU Units are
referred to as “highly functional, large-capacity CPU Units.”
CQM1-CPU11-E and
CQM1-CPU21-E CPU Units
Built-in Analog Setting
Function
Built-in Pulse I/O Function
Built-in ABS Interface
Function
CPU Unit Section 2-1

Sysmac CQM1 Specifications

General

Manufacturer	Omron
Operating Temperature	0 to 55°C
Humidity	10 to 90% RH (non-condensing)
Power Supply	100 to 240 VAC or 24 VDC (depending on model)
Programming Language	Ladder Diagram, Instruction List
Communication Ports	RS-232C
Expansion	Expansion I/O units available
Analog I/O	Available via expansion units
Instruction Set	Basic and advanced instructions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
