Tatuus T-421 - Suspension Geometry; Front Suspension Geometry

RELEASE 2.1.0
106
5.7 SUSPENSION GEOMETRY
5.7.1 Front suspension geometry
The origin is located at the intersection of front wheel axle and reference plane, the coordinate of the contact
point is then below the reference plane by a value of Rd-Zn where Rd is the Rolling Radius of the tire and Zn
is the z coordinate of point N.
X
Y
Z
A
-50,0
210,8
243,9
B
9,0
657,5
225,1
C
300,0
232,1
246,0
D
-50,0
210,8
392,9
E
32,1
628,0
364,2
F
300,0
232,1
382,5
S
-64,4
677,5
361,6
T
-130,0
205,9
393,5
N
0,0
757,5
253,0
L
0,0
757,5
Z
N
-R
d
U
389,0
80,0
561,5
V
82,4
81,3
560,8
P
80,0
156,0
522,1
Q
80,0
133,0
477,7
M
41,0
154,4
522,9
W
16,0
648,6
267,0
X
-170,0
90,0
420,5
Y
-170,0
0,0
420,5
Z
-170,0
90,0
550,0
R
46,2
91,6
555,5
