RELEASE 2.1.0

5.2 FRONT WISHBONES BRACKETS ASSEMBLY

During the assembly pay attention to the orientation of the wishbones brackets studs (items #1 below), the

thread undercut side is the one that must be assembled in the chassis.

CHASSIS

Thread undercut
