14.1.7 ESA rocker bolts
Please find below specification for ESA rocker bolts, tightening torque and prescription for installation
Item
p/n
Description
Qty
1
ISO14580-M5X8-CL 12.9
Hexalobular socket screws M5, length 8 mm, grade 12.9
3
2
ISO7089-5
Washer 5.3x10x1
3
Bolts should be fitted with Loctite 270, applying a tightening torque of 4.5 Nm.
If bolts are removed for maintenance please make sure of cleaning them with isopropyl alcohol before
applying Loctite.
