2.3 EXTRACTABLE SEAT & GAP FILLERS
The F4 cockpit has been design in a way that drivers with a spread of body size from 1.50m to 1.97m may be
fitted in the car. In order to fit correctly the drivers and achieve a limitation of the seat foam inserts thickness
of 50mm, different size of extractable seats (small, medium and large) are available.
To ease the choice of seat size, a possible solution could be to consider values in between the 3 above to set
the ranges, please refer to the table below.
SMALL range
up to 1670 mm
MEDIUM range
1670 mm – 1830 mm
LARGE range
Over 1830 mm
The values in the table are to be considered as a reference example.
70 kg
89 kg
52 kg
Nom. Weight:
1499 mm
1755 mm
1977 mm
