Tatuus T-421 - Differential Block Disassembly

RELEASE 2.1.0
162
13.11.8 Differential block disassembly
• Remove the circlips
○
1 .
• Remove the cover
○
2 .
• Remove the outside circlip "wire locking"
○
3 .
• Remove the gear axles from the case, extract the planet gears and the sun gears from the cage.
1
2
3
