Tatuus T-421 - Halo; Installation Procedure

RELEASE 2.1.0
30
2.10 HALO
2.10.1 Installation procedure
General notes:
grey arrow: unscrew/screw but not tighten
green arrow: screw and tighten
When installing the HALO, apply on the bolts some water and oxidation resistant grease. For example, the
PETRONAS TUTELA Z2 grease is suitable for this purpose.
1. Insert the front fairing (33-01-043) on the HALO center bar
2. Install the front bracket (28-01-010) on the HALO
