8 BRAKE SYSTEM
8.1 BRAKE SYSTEM SETUP
Master cylinder suggested configuration:
FRONT ø
REAR ø
Standard
19.05 mm
20.64mm
The following table shows the front brake balance when the balance bar is set at the mid adjustment (master
cylinders have the same distance from trunnion):
REAR
5/8”
(15.88mm)
3/4”
(19.05mm)
13/16”
(20.64mm)
7/8”
(22.23mm)
1”
(25.4mm)
FRONT
5/8”
(15.88mm)
50%
59%
63%
DO NOT USE
DO NOT USE
3/4”
(19.05mm)
DO NOT USE
50%
54%
57.6%
DO NOT USE
13/16”
(20.64mm)
DO NOT USE
DO NOT USE
50%
53.7%
60%
7/8”
(22.23mm)
DO NOT USE
DO NOT USE
DO NOT USE
50%
56%
1”
(25.4mm)
DO NOT USE
DO NOT USE
DO NOT USE
DO NOT USE
50%
