Tatuus T-421 - Selector Axle

To Next Page

To Previous Page

RELEASE 2.1.0

176

13.12.5 Selector Axle

Item

Part number

Description

Glue

Torque

(DaN m)

0301422

CHC M16x16 Bolt

243

1,5

F0059021

Shoulder screw

243

2,5

0301138

CHC M5x12 Bolt

222

0,8
