14.1.4 ESA Warnings
In the first page of the display are shown also the following warning messages related to the barrel sensor:
• F: barrel sensor position out of mechanical range. The barrel is stuck in a not engaged position
between two gears.
• E: barrel sensor position out of electrical range. The electrical output of the barrel sensor is:
< 500 mV or >4500 mV.
Potential causes:
o Barrel sensor faulty or disconnected.
o Short circuit on harness.
