Tatuus T-421 - Optional Damper Sensors

RELEASE 2.1.0
111
5.8 OPTIONAL DAMPER SENSORS
The dampers sensor kit is available from Tatuus.
Front and rear rockers are designed for the installation of dedicated linear sensors assembly, a specific
adaptor allows to install the potentiometers on the shock absorbers clamps on the chassis side.
FRONT
REAR
Motion ratio
Motion ratio
Wheel/Pot: 2 [mm/mm]
Wheel/Pot: 2 [mm/mm]
Spring/Pot: 1,8 [mm/mm]
Spring/Pot: 1,6 [mm/mm]
For the optional sensors and adaptor looms, please refer to the T-421 spare parts catalog. For the analog
spare input configuration in data logging, please refer to the engine manufacturer.
Warning:
Please refer to the sporting regulation about the installation and use of the damper sensors in the official
events.
