Version: 1.06 122
- 48 VDC
Voltage / Current
V in -60 to –24 VDC
Output current on the BUS (3.3V)
2 A
Consumption 10 mA
Power
Input Power at I out=2 A Maximum: 12 W
Input Power in over load or short-circuit Maximum: 65 W
Efficiency Minimum: 60% at 2 A
Protection
Test Automatic test of the access of the card by the CPU
(see LED ‘CS’ below)
Input voltage inversion Maximum: 60 VDC
EMC protection
Over load and short-circuit Maximum 1 second every minute
Above this time, risk of permanent damage (output line is
opened)
Isolation
No isolation Between Input and Output GND
No isolation Between GND and Earth
Temperature
Storage -40 to 70 °C
Working (inside the card) Standard: -40°C to 85°C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20°C to 70°C
Hygrometry 15 to 95 % without condensation
LED
Main Input Voltage present
CS Card Selection: the card corresponds to a card declared in
TWinSoft.
ER Error: The type of the card does not correspond to the one
declared in TWinSoft.
Input / Output
Temperature input Use: measurement of the card internal temperature
Internal input
Precision: 5 °C
Voltage input Use: measurement of the Input voltage
Internal input
Precision: 1 %
Dimensions
Without connector Height x Length x Depth: 150 x 83 x 29 mm
Weight 245 gr.
