Version: 1.06 140
16 x Digital Outputs (next)
Isolation
2 groups isolated Isolation by group of 8 outputs
From the Ground Isolation from the CPU ground and the earth
Level of isolation 1500 Vrms
- between group
- between Outputs and ground
- between Outputs and earth
Protection
Test Automatic test of the access of the card by the CPU
(see LED ‘CS’ above)
Protection diode Protection against inverted voltage when working with inductive load
WARNING:
when the output is connected to a DC relay
driving an AC relay, the AC relay must be protected with a RC
circuit
Over load Maximum: 60 VDC
Reverse voltage Maximum: 55 VDC
Short-Circuit + Over load Thermal protection with automatic recovery
Voltage / Current
Working voltage on V+ 6 to 60 VDC
Working current on V+ Maximum: 200 mA
Voltage per output Maximum: 60 VDC (depending on V+)
Short-Circuit current Minimum: 0.2 A
Typical: 0.9A
Maximum: 1.2A
Impedance Typical: 1 ohm
Maximum: 10 ohms
Consumption 80 mA
Temperature
Storage -40° to 70 °C
Working (inside the card) Standard: -40°C to 85 °C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20 °C to 70 °C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x length x Depth: 150 x 83 x 29 mm
Weight 258 gr
