Version: 1.06 159
8 RTD (next)
T
ECHNICAL
S
PECIFICATIONS
General
Quantity 8 temperature inputs
Signals
Choice between Pt100, Pt1000, Ni100, Ni1000
2 wires or 3 wires
The selection of the probe is done by the cabling used. No hardware or
software configuration is required
Resolution 15 bits
Precision
- Ni100, Pt100
- Ni1000, Pt1000
0.1 °C
0.1 °C
Filter 1 sec
Maximum length of cable 100 m
Maximum resistance of the
cable
20 Ω
Replacement Hot insertable/removable. There is no risk to damage hardware, but
a reset is required.
Test Automatic test of the access of the card by the CPU
(See LED ‘CS’ below)
LED
CS Card Selection: the card corresponds to a card declared in TWinSoft.
ER Error: The type of the card does not correspond to the one declared in
TWinSoft.
Isolation
Between channel Non isolated
Channel to Ground/Earth Non isolated
Temperature
Storage -20°C to 70°C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20°C to 70°C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x Length x Depth: 150 x 83 x 29 mm
Weight 300 g
