Techno Trade TBOX MS - Page 160

Version: 1.06 160
8 RTD (next)
C ABLING – A NALOG I NPUTS
Description:
Cabling Probes 2 Wires
Description:
Cabling Probes 3 Wires
Group A
Group B
There is no isolation.
It means Gnd are connected
together and the Earth.
1 2 3 4 5 6 7 8 9 10
Gnd
Gnd
1 2 3
4 5
6 7 8
9 10
Gnd
Gnd
1 2 3 4 5 6 7 8 9 10
Gnd
Gnd
1 2 3
4 5
6 7 8
9 10
Gnd
Gnd
