Version: 1.06 162
4 ANAOUT (next)
T
ECHNICAL
S
PECIFICATIONS
General
Quantity 4 analog outputs
Signals
- for each output
Choice between 4..20ma OR –10V..+10V
The selection of the signal is done by the cabling used. No hardware or
software configuration is required
ADC converter 12 bits, bipolar
Mode
- Current
Active mode. Supplies a nominal voltage of 24 VDC.
Full Range
- Current
- Voltage
0 to 20mA
-10V to +10V
Resolution
- Current
- Voltage
12 bits
11 bits + sign
Precision
- Current
- Voltage
5 µA
5 mV
Reactivity
- Current
- Voltage
25 msec
1 msec
Load impedance limit
- Current
- Voltage
Resistance of the actuator:
≤ 1000 Ω : gives a drop of 20 V, maximum allowed.
> 3000 Ω : gives a current of 3.33 mA, maximum allowed.
Consumption Tbd
Replacement Hot insertable/removable. There is no risk to damage hardware, but
a reset is required.
Test Automatic test of the access of the card by the CPU
(See LED ‘CS’ below)
Digital Input
Validity input associated to
each analog output 4..20mA
Returns ‘0’ when signal < 2.4mA and > 21.6mA
Returns ‘1’ when the signal is valid.
LED
CS Card Selection: the card corresponds to a card declared in TWinSoft.
ER Error: The type of the card does not correspond to the one declared in
TWinSoft.
Isolation
4 channels isolated Isolation one by one
From the Ground Isolation from the CPU ground and the earth
Level of isolation 500 Vrms between each output
1500 Vrms between each output and earth
Temperature
Storage -20°C to 70°C
Working (ambient) Standard: -5°C to 50°C
Ruggedized: -20°C to 70°C
Hygrometry 15 to 95 % without condensation
Dimensions
Without connector Height x Length x Depth: 150 x 83 x 29 mm
Weight 300 g
