Annex C Messages of DUT-E CAN data transfer protocol
DUT-E fuel level sensors. Operation manual. Version 8.1
© Technoton, 2020 109
Table C.1 continued
#
Message name
Message parameters
Message content
Broadcast
interval
Data length
Extended data page
(EDP)
Data page (DP)
PDU format (PF)
PDU specific (PS)
Default priority (P)
Parameter
group number
(PGN)
Initial
position
Length
Valuable data
Suspect
Parameter
Number
(SPN)
SAE J1939
3
PGN 63008
“Unit state”
1000
ms
8
0
0
246
32
6
63008
(0xF620)
1.1
2 bytes
Ignition Key State
521049
1.3
2 bytes
Cross-Axle Blocking Status
521054
1.5
2 bytes
PTO Switch Status
521059
1.7
2 bytes
Events Status
521136
2.1
2 bytes
Active Faults Presence
Status
521137
2.3
2 bytes
Passive Faults Presence
Status
521138
2.5
2 bytes
Unit Power Status
521129
2.7
4 bytes
Engine Mode by Fuel Rate
521181
3.3
4 bytes
Movement mode based on
vehicle speed
521180
3.7
2 bytes
Vehicle Fuel Saving Mode
Status
521139
4.1
4 bytes
Axle Weight Mode
521182
4.7
2 bytes
GPS/GLONASS Receiver
Status
521134
5.1
2 bytes
GPS/GLONASS Antenna
Status
521135
5.3
2 bytes
Modem Power Status
521130
5.5
2 bytes
Modem Registration Status
521131
8
1 byte
Reserved_8
524000
— the bytes are not used.
