7.4.1 ISDN TRACE OUTPUT
Trace output for DSS1 is in hexadecimal notation. You can use the external tool
TraceView.exe to translate
offline trace output. You will find the tool in the Software folder on the enclosed CD. The GATE Manager’s trace
window can also display translated online traces.
Example: The following example shows an untranslated DSS1 trace:
7.4.2 CALL FORWARDING TO SIP TRACE OUTPUT
To activate the trace output, set the following options in the trace mask:
 fctrans: Shows the internal translation from ISDN facility to SIP message
 fcisdn: Translates the ISDN facility messages<argumente>
The arguments define which traces are to appear and are separated by a comma. The following arguments apply
for each module:
 trclevel=[info; error; debug]
Info messages allow the user to observe the progress of the translation process. Detailed information is
available at the debug level. Errors (defualt) always appear.
 fctype=[all;cf]
This parameter allows the user to select the properties for trace output. The default setting is all.
Example:
7.4.3 POTS TRACE OUTPUT
Trace output for FXS and FXO controllers is in ASCII (text notation. the
<trace> part (see Chapter 7.4 ) is con-
sists of
<trace type>, followed directly by <trace output>.
17.05.06-09:54:40,Start 11.7a (L3)
[09:55:14.58] r[00]: 00 01 02 02 08 02 00 02 05 04 03 80 90 a3 18 03 a1 83 81 6c 02 81 31 70 06 81 31 32 33
34 35 7d 02 91 81
[09:55:14.58] s[00]: 02 01 02 04 08 02 80 02 0d 18 03 a9 83 81
[09:55:14.58] s[01]: 00 01 a8 9a 08 02 00 46 05 04 03 80 90 a3 18 03 a1 83 89 6c 02 81 31 70 06 81 31 32 33
34 35 7d 02 91 81
[09:55:14.58] r[01]: 02 01 9a aa 08 02 80 46 0d 18 03 a9 83 89
[09:55:14.86] r[01]: 02 01 9c aa 08 02 80 46 01
[09:55:14.86] s[00]: 02 01 04 04 08 02 80 02 01
[09:55:16.73] r[01]: 02 01 9e aa 08 02 80 46 07 29 05 05 07 01 09 33 4c 07 01 81 31 32 33 34 35
[09:55:16.73] s[01]: 00 01 aa a0 08 02 00 46 0f
[09:55:16.73] s[00]: 02 01 06 04 08 02 80 02 07 29 05 05 07 01 09 32 4c 07 01 81 31 32 33 34 35
[09:55:16.73] r[00]: 00 01 04 08 08 02 00 02 0f
[09:55:44.30] r[00]: 00 01 06 08 08 02 00 02 45 08 02 80 90
[09:55:44.35] s[01]: 00 01 ac a0 08 02 00 46 45 08 02 80 90
[09:55:46.71] r[01]: 02 01 a0 ae 08 02 80 46 4d
[09:55:46.71] s[01]: 00 01 ae a2 08 02 00 46 5a
[09:55:46.71] s[00]: 02 01 08 08 08 02 80 02 4d
[09:55:46.71] r[00]: 00 01 08 0a 08 02 00 02 5a
17.05.06-09:51:33,End
fctrans:trclevel=info,fcisdn:trclevel=error
