SYSTEM MAINTENANCE AND SOFTWARE UPDATE
CHAPTER 7
112
ECOTEL 3G 16.1. Revised: 1 March 2011.
7.4.3.5 TON TRACE OUTPUT
The trace output
ton provides information about tone recognition in the B-channel. Since they appear unabridged
and are not of importance, no description is necessary.
7.4.4 MOBILE TRACE OUTPUT
The trace output for Mobile calls appears in hexadecimal notation. Its format is the same as that for ISDN output.
Table 7.13 and Table 7.14 describe the contents of mobile trace output.
Table 7.13 Request Messages to the Mobile Module
Hex Value Description
00
Setup
01
Connect
02
Disconnect
03
SMS
04
DTMF
05
Set Config
06
Get Config
07
LED
08
Restart
09
Switch SIM
Table 7.14 Incoming, Indication Message from the Mobile Module
Hex Value Description
0B
Alert
0C
Voice Indication
0D
Connect
0E
DTMF
0F
Setup
10
Disconnect
