13.7 SENDING THE CALLER’S OAD IN AN SMS MESSAGE
The following configuration activates a feature whereby the system sends an SMS message to announce a caller’s
OAD before the actual call is being put through. The SMS message contains a configurable text and the caller’s
OAD so that the mobile user knows who is going to call him through the ECOTEL’s interface.
Make the following configuration in the
pabx.cfg’s [System] section:
SMSCLI=<“message content”>
You must enter the text that is to be sent in quotation marks. The OAD will be attached to this text message.
In the
route.cfg, adjust your mapping entries to contain the SMSCLI parameter:
MapAll<direct>=<num> SMSCLI
Do not forget that the SMS center number must be defined (refer to Table 5.16 on page 5-64 for an explanation)
and that the following entry must appear in the
route.cfg for transmission to be possible:
MapAllSMS=<port> map all SMS messages to a port or
MapAllSMS=<LAIN> map all SMS messages to a LAIN
The mapping to a LAIN requires that
CHADDR is added to the pabx.cfg’s Subscriber line, to change the
controller definition to the SIM card’s LAIN.
Example: In the following example, an SMS message is sent to the number 01551234567 through the
LAIN 26212 to announce a call to this number. Digit collection is activated.
pabx.cfg:
route.cfg:
MapAllSMS=26212
MapAll015557777=|26212015557777<<17
MapAll01555=|2621201555<<17 VOICE
MapAll01556=|2621201556<<17 VOICE
MapAll01444=|2621301444<<17 VOICE
MapAll01445=|2621301445<<17 VOICE
No SMS message will be generated if the service code DATA appears in the mapping
entry.
SMSCLI="You are going to get a call from"
MapAllSMS=26212
MapAll01551234567=|2621201551234567 SMSCLI
