SIGNALING AND ROUTING FEATURES
CHAPTER 8
154
ECOTEL 3G 16.1. Revised: 1 March 2011.
8.4 CLIP AND CLIR
8.4.1 ROUTING CLIP AND CLIR CALLS
This function allows you to route calls with Calling Line Identification Presentation (CLIP) differently from calls with
Calling Line Identification Restriction (CLIR). For example, all CLIP calls can be rejected, so that only calls that do
not present the calling number or calls without a calling party number (e.g. analog) are transmitted through the
ECOTEL.
Use the following configuration to define the various routing methods:
InsertCLIR=On activates this mode. 01 is the service indicator for telephony (analog and ISDN) and is used to
differentiate these calls from remote administration calls.
Restrict9=OK 01 means that all telephony calls
without a calling number are put through.
Restrict|9=OK 01 means that all CLIR telephony calls are put
through.
Restrict90=FAIL 01 means that all CLIP telephony calls are rejected with No Channel Available
as rejection cause when they are mapped to
MapInFAIL=&aa.
8.4.2 ROUTING CALLS WITHOUT CLIR
This function enables you to bypass CLIR for calls through the defined mobile port. The following configuration in
pabx.cfg activates this function:
MapAll0=40DATA:0 DATA
...
MapAll9=40DATA:9 DATA
MapAll0=|40DF:0<<24
...
MapAll9=|40DF:9<<24
Restrict40=In
MapAllIn=10
[Voip:DF]
VoipDirection=IO
...
VoipCompression=g711a g729 trp t38
...
[Voip:DATA]
VoipDirection=Out
...
VoipCompression=trp
VoipECE=No
...
...
InsertCLIR=On
...
Restrict9=OK 01
Restrict|9=OK 01
Restrict90=FAIL 01
...
MapInOK00491555=2200491555
MapInFAIL=&aa
...
Subscriber<xx>=...UMTS[...,!CLIR]...
