SYSTEM MAINTENANCE AND SOFTWARE UPDATE
CHAPTER 7
107
ECOTEL 3G 16.1. Revised: 1 March 2011.
Included in the possible uses for this feature is remote access to the ECOTEL when the IP connection does not have
a fixed IP address. In this case, you can access the system, for example with the GATE Manager, if the host name
is used in the Remote Number dialog. Example entry in the Remote Number dialog:
IP:host.domain.de
7.4 TRACE
During operation, the trace readouts of the ECOTEL can be saved in a file or transmitted with remote maintenance
directly. The trace options must be turned on in the GATE Manager (offline or online trace) or via FTP raw com-
mands (see Chapter 4.11.3 ). Trace results presented here are for BRI, analog, mobile and VoIP interfaces, and
for the following services in various levels:
Figure 7.1 GATE Manager: Online Trace Activation Window
Table 7.8 Trace Options
Option Definition
Mail Output for all SMTP packets.
NumberPortability Output of all packets for communication with the iMNP.
vGATE Output of all packets for communication with the vGATE.
VoiceCodecs Output of RTCP information described under VP module.
PPP Output of PPP connection information.
DTMF Output for DTMF tone recognition.
Remote Output for GATE Manager and NMS communication.
