12.4 CALLBACK WITH DTMF AND OAD AS CALLBACK NUMBER
The user calls a number to trigger callback to his calling number (OAD). After the alert tone, the system or the user
hangs up and the user is called back. When he takes the call, he is requested by announcement to enter the des-
tination number using DTMF tones. The connection to the destination number is then established.
The following entries in
route.cfg will initiate callback to the calling party’s number:
MapAll<number>=CALLB
This entry contains the number that needs to be called to trigger callback.
MapCallbackAlert=<sec>
If this optional parameter is configured, the ECOTEL will release the call after the given number of seconds.
MapAllCB=<port>
Calls back the calling party’s number via the defined port.
MapAllDTMF=<DTMFport>DTMF
Maps to the port that is needed for recognizing DTMF tones.
MapAllDLA=<port>
Sends all digits that have been entered as DTMF to the specified port.
The letter “B” in
CALLB can be replaced by any capital letter from C to Z to allow for different routings. Corre-
spondingly, “B” in
MapAllCB and “A” in MapAllDLA need to be replaced by a matching capital letter C to Z:
MapAll<number>=CALLC
MapAll<number>=CALLD
...
MapAll<number>=CALLZ
corresponds with:
MapAllCC=<port>
MapAllCD=<port>
...
MapAllCZ=<port>
corresponds with:
MapAllDLC=<port>
MapAllDLD=<port>
...
MapAllDLZ=<port>
Restrict20=IN
MapAllIN=41DTMF
MapAllDLA=9
MapAll12345=41DTMFCa
MapAllDLC=10
