TELES ECOTEL - Remote Output

SYSTEM MAINTENANCE AND SOFTWARE UPDATE
CHAPTER 7
143
ECOTEL 3G 16.1. Revised: 1 March 2011.
7.4.6 REMOTE OUTPUT
This trace option provides output for communication with the GATE Manager or NMS. To activate this option, ac-
tivate the section Remote in the GATE Manager. You can choose the depth of the trace output: Error is limited
to error messages; Debug provides information; Detail provides the entire packet.
Output is defined with a
g, and the port number is 99.
The following output shows an established GATE Manager connection:
[16:00:43.72] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.72] y[04]: h225 decode rc 0, q931 msg 62 (6), len 64
[16:00:43.72] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.72] i[04]: h245rcv(1) cr 7 CloseLogicalChannelAck cn=1
[16:00:43.72] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.72] y[04]: h225 decode rc 0, q931 msg 62 (6), len 83
[16:00:43.72] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.72] i[04]: h245rcv(1) cr 7 OpenLogicalChannelAck cn=1 sessid=1 media=172.20.0.100:29000
[16:00:43.72] i[04]: rtp start cr 7 ch 1 li 1 ri 1 st 3 fx 0 cp G txm 1
[16:00:43.72] i[04]: rtp start cr 7 ch 1 li 1 ri 1 st 3 fx 1 cp G txm 1
[16:00:43.79] a[04]: ac49x start2 ch=0 remote=ac100064:29000 rc=0
[16:00:43.79] a[04]: ac49x start fax ch=0 doing fax already
[16:00:46.70] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 3 0 0 0 0
[16:00:48.95] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 8 0 0 0 0
[16:00:49.60] a[04]: ac49x ch 0 fax/data 0 0 6
[16:00:49.60] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 3 0 0 0 0
[16:00:51.53] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 12 0 0 0 0
[16:00:51.65] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 20 0 0 0 4
[16:00:52.94] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 20 0 0 0 4
[16:00:54.25] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 3 0 0 0 0
[16:00:55.73] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 16 0 0 0 0
[16:00:56.44] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 21 0 0 0 4
...
[16:01:25.93] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 21 0 0 0 4
[16:01:27.13] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 3 0 0 0 0
[16:01:28.26] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 18 0 0 0 0
[16:01:29.05] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 3 0 0 0 0
[16:01:30.56] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 17 1 0 0 0
[16:01:31.62] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 3 1 0 0 0
[16:01:32.72] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 0 15 1 0 0 0
[16:01:33.13] r[02]: 00 81 5e 34 08 01 01 45 08 02 80 90
[16:01:33.13] i[04]: pstnrcv terminate connection (3201) cr 7 cau 90 err 0 state 16 ch 1 rsid 1
[16:01:33.13] i[04]: rtp stop cr 7 ch 1
[16:01:33.13] x[04]: h225snd relack cr 7 cau 0x90
[16:01:33.13] i[04]: h225connection s 4 close
[16:01:33.13] i[04]: CloseSysFd 4 (st 22)
[16:01:33.16] s[02]: 02 81 34 60 08 01 81 4d
[16:01:33.16] a[04]: ac49x ch 0: in 5714 out 99508
[16:01:33.16] a[04]: ac49x stop ch=0
[16:01:33.21] a[04]: ac49x ch 0 rtcpR 2 ji 234 rt 15139031 fl 0 in 15139047 out 2228
[16:01:33.22] r[02]: 00 81 60 36 08 01 01 5a
g[99]:moip: accept rc=2 ipad=<ip address> port=<port>
Table 7.55 Remote Output
Trace Output Description
<ip address>
Remote system’s IP address with GATE Manager.
