SYSTEM MAINTENANCE AND SOFTWARE UPDATE
CHAPTER 7
142
ECOTEL 3G 16.1. Revised: 1 March 2011.
Fax Call
[16:00:33.87] r[02]: 00 81 54 2c 08 01 01 05 04 03 80 90 a3 18 01 83 7d 02 91 81
[16:00:33.87] s[02]: 02 81 2c 56 08 01 81 0d 18 01 89 1e 02 82 88
[16:00:36.99] r[02]: 00 81 56 2e 08 01 01 7b 70 02 81 31
[16:00:37.17] r[02]: 00 81 58 2e 08 01 01 7b 70 02 81 32
[16:00:37.33] r[02]: 00 81 5a 2e 08 01 01 7b 70 02 81 33
[16:00:37.54] r[02]: 00 81 5c 2e 08 01 01 7b 70 02 81 34
[16:00:40.46] s[02]: 02 81 2e 5e 08 01 81 02 1e 02 82 88
[16:00:40.46] i[04]: pstnrcv setup dad DF:1234 oad cc 0 id 11d007
[16:00:40.46] i[04]: pstnrcv get_voipcfg <DF>
[16:00:40.46] i[04]: rtp start cr 7 ch 1 li 1 ri 0 st 1 fx 0 cp E txm 1
[16:00:40.46] i[04]: h225connect to 172.20.0.100 cr 7
[16:00:40.46] x[04]: h225snd setup dad 1234 cr 7
[16:00:40.46] y[04]: h225rcv tpkt msg d h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:40.46] y[04]: h225 decode rc 0, q931 msg d (11), len 32
[16:00:40.46] y[04]: h225rcv msg d (11) h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:40.54] a[04]: ac49x start(201) ch=0 local=29000 remote=0:0 agg=0
[16:00:40.54] a[04]: Ac49xOpenChannelConfiguration ch=0 rc=0
[16:00:40.54] a[04]: Ac49xT38ChannelConfiguration ch=0 rc=0
[16:00:40.54] a[04]: Ac49xActivateRegularRtpChannelConfiguration ch=0 rc=0
[16:00:40.69] y[04]: h225rcv tpkt msg 1 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:40.69] y[04]: h225 decode rc 0, q931 msg 1 (3), len 119
[16:00:40.69] y[04]: h225rcv faststart <E4>
[16:00:40.69] y[04]: h225rcv alert h225cr 7 FS:1(E,172.20.0.100,29000) TUNN:1 H245:0(0,0)
[16:00:40.69] i[04]: rtp start cr 7 ch 1 li 1 ri 1 st 2 fx 0 cp E txm 1
[16:00:40.69] s[02]: 02 81 30 5e 08 01 81 01 1e 02 82 88
[16:00:40.70] a[04]: ac49x start2 ch=0 remote=ac100064:29000 rc=0
[16:00:40.77] a[04]: ac49x ch 0 rtcpR 0 ji -1 rt -1 fl 65535 in 0 out -1
[16:00:40.77] a[04]: ac49x ch 0 establish
[16:00:40.88] a[04]: ac49x ch 0 jitter buffer 35 1 0 1 0 0 0 0
[16:00:40.91] y[04]: h225rcv tpkt msg 7 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:40.91] y[04]: h225 decode rc 0, q931 msg 7 (2), len 77
[16:00:40.91] y[04]: h225rcv connect h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:40.92] i[04]: pstnsnd connect cr 7
[16:00:40.92] s[02]: 02 81 32 5e 08 01 81 07 29 05 06 03 18 10 00
[16:00:41.91] a[04]: ac49x ch 0 jitter buffer 85 4 0 4 2 0 0 0
[16:00:41.95] a[04]: ac49x ch 0 rtcpT 1 ji 195 rt 0 fl 0 in 272 out 1340
[16:00:41.95] a[04]: ac49x ch 0: in 940 out 7926
[16:00:43.15] a[04]: ac49x ch 0 fax/data 0 0 1
[16:00:43.15] a[04]: ac49x ch 0 fax/data 0 0 0
[16:00:43.30] a[04]: Ac49xActivateFaxRelayCommand(1) ch 0 rc 0
[16:00:43.30] a[04]: ac49x ch 0 fax detected(1)
[16:00:43.30] i[04]: vpinfo fax detected cr 7 ch 1
[16:00:43.30] i[04]: h245snd(1) cr 7 TerminalCapabilitySet <EG>
[16:00:43.30] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.30] y[04]: h225 decode rc 0, q931 msg 62 (6), len 63
[16:00:43.30] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.30] i[04]: h245rcv(1) cr 7 TerminalCapabilitySetAck
[16:00:43.33] a[04]: ac49x ch 0 faxrelay 0 0 0 0 0 0 0 0 1 2 0 0 0 0
[16:00:43.50] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.50] y[04]: h225 decode rc 0, q931 msg 62 (6), len 147
[16:00:43.50] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.50] i[04]: h245rcv(1) cr 7 TerminalCapabilitySet peer=<EG> cfg=<EG>
[16:00:43.50] i[04]: h245snd(1) cr 7 TerminalCapabilitySetAck
[16:00:43.50] i[04]: h245snd(1) cr 7 RequestModeT38
[16:00:43.68] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.68] y[04]: h225 decode rc 0, q931 msg 62 (6), len 64
[16:00:43.68] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.68] i[04]: h245rcv(1) cr 7 RequestModeAck
[16:00:43.68] i[04]: h245snd(1) cr 7 CloseLogicalChannel cn=1
[16:00:43.68] i[04]: h245snd(1) cr 7 OpenLogicalChannel cn=1 cpr=G sessid=1 ctrl=172.20.0.200:29001
[16:00:43.69] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.69] y[04]: h225 decode rc 0, q931 msg 62 (6), len 68
[16:00:43.69] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.69] i[04]: h245rcv(1) cr 7 CloseLogicalChannel cn=1 (1)
[16:00:43.69] i[04]: h245snd(1) cr 7 CloseLogicalChannelAck cn=1
[16:00:43.69] y[04]: h225rcv tpkt msg 62 h225cr 7 addr 172.20.0.100 pt 800e7000
[16:00:43.72] y[04]: h225 decode rc 0, q931 msg 62 (6), len 92
[16:00:43.72] y[04]: h225rcv facility h225cr 7 FS:0(-,0,0) TUNN:1 H245:0(0,0)
[16:00:43.72] i[04]: h245rcv(1) cr 7 OpenLogicalChannel cn=1 cpr=G sessid=1 ctrl=172.20.0.100:29001
[16:00:43.72] i[04]: h245snd(1) cr 7 OpenLogicalChannelAck cn=1 sessid=1 media=172.20.0.200:29000
