SYSTEM MAINTENANCE AND SOFTWARE UPDATE
CHAPTER 7
113
ECOTEL 3G 16.1. Revised: 1 March 2011.
Example: The following example shows a mobile call through the fourth mobile controller:
7.4.5 VOIP TRACE OUTPUT
As described above in Chapter 7.4 , there are four modules for VoIP traces. The groups
x (send), y (receive) and
i (information and internal output) appear when a Layer2 or Layer3 offline or online trace is started. Group a
(RTCP output) only appears when the module Voice Codecs is active.
Particularly in the case of VoIP connections (protocols H.323 and SIP), the trace output is quite extensive and ab-
breviations make it difficult to keep track of the results. The following list contains a description of H.323 output.
Output for the signaling protocol SIP is transmitted in ASCII and translated for better legibility. Since they are dis-
played unabridged, no description is necessary. Information and internal output traces correspond with the H.323
output and are described in the following tables. For ENUM, please refer to Chapter 7.4.5.6 .
11
SMS
12
SMS Confirmation
13
Error
16
Get Config Confirmation
18
Dial-In Call Proceeding
19
USSD
1A
Restart Indication
Status Request
[14:57:51.80] s[04]: 06
Status Information:
[14:57:51.80] r[04]: 16
Setup Request:
[14:57:52.29] s[04]: 00 4c 93 04 00 00 00 35 36 36 37 00 35 38 2c 36 34 36 2c 33 30 2c 2c 2c 30 2c 2c 2c
30 2c 32 36 32 2c 30 37 2c 00 72 64 09 75 70 20 7b 64 35 7d 20 27 2e 2e 2b 43 43 45 44 3a 20 32 36 32 2c
30 37 2c 34
Dial End:
[14:57:55.47] r[04]: 18
Alert:
[14:57:55.63] r[04]: 0b
Connect Indication:
[14:57:56.63] r[04]: 0d
Disconnect Request:
[14:59:54.13] s[04]: 02 4c 93 00
Disconnect Indication:
[14:59:54.19] r[04]: 10
Table 7.14 Incoming, Indication Message from the Mobile Module (continued)
Hex Value Description
