SYSTEM MAINTENANCE AND SOFTWARE UPDATE
CHAPTER 7
123
ECOTEL 3G 16.1. Revised: 1 March 2011.
Fax relay is activated for the corresponding channel:
The following output shows various values for fax transmission (see Table 7.32 for a description of the values):
2 ANS_TONE_2100_FAX_CED_OR_
MODEM
FAX-CED or modem-ANS (answer tone,
2100 Hz)
3 ANS_TONE_WITH_REVERSALS ANS (answer tone with reversals)
4 ANS_TONE_AM ANSam (AM answer tone)
5 ANS_TONE_AM_REVERSALS ANSam (AM answer tone with reversals)
6 FAX_V21_PREAMBLE_FLAGS FAX-V.21 preamble flags
7 FAX_V8_JM_V34 FAX-V.8 JM (fax call function, V.34 fax)
8 VXX_V8_JM_VXX_DATA V.XX-V.8 JM (data call function, V-series mo-
dem)
9 V32_AA V.32 AA (calling modem tone, 1800 Hz)
10 V22_USB1 V.22 USB1 (V.22(bis) unscrambled binary
ones)
11 V8_BIS_INITIATING_DUAL_TONE V.8bis initiating dual tone (1375 Hz and
2002 Hz)
12 V8_BIS_RESPONDING_DUAL_TONE V.8bis responding dual tone (1529 Hz and
2225 Hz)
13 VXX_DATA_SESSION V.XX data session
14 V21_CHANNEL_2 V.21 channel 2 (mark tone, 1650 Hz)
15 V23_FORWARD_CHANNEL V.23 forward channel (mark tone, 1300 Hz)
16 V21_CHANNEL_1=18 V.21 channel 1 (mark tone, 980 Hz)
17 BELL_103_ANSWER_TONE Bell 103 answer tone, 2225 Hz
18 TTY TTY
19 FAX_DCN FAX-DCN (G.3 fax disconnect signal)
a[<controller>]: Ac49xActivateFaxRelayCommand(1) ch <ch> rc <cr>
a[<controller>]: ac49x ch <ch> faxrelay: n1 n2 n3 n4 n5 n6 n7 n8 n9 n10 n11 n12 n13 n14 n15 n16 n17
Table 7.31 faxordatasignalevent (continued)
Value Definition Description
