ONLINE TRAFFIC MONITOR
CHAPTER 11
200
ECOTEL 3G 16.1. Revised: 2011.
Example: The following entry shows the pabx.cfg configuration file changed according to the formula:
Example: In the following CDR entry,
<num> consists of a four-digit number (0000) that is included in the
CDR.
Differentiating Between SIM Cards
The CDR can contain the IMSI (International Mobile Subscriber Identity), which identifies each SIM card used:
Example:
The following example shows the
pabx.cfg configuration file changed according to the formula:
Example:
Activating Peer Data for VoIP Calls
To generate a VoIP-call CDR entry that includes IP addresses for the remote device’s signaling and voice data, audio
codec and frame size, the entry
VoipIpLogging=Yes must be included in the VoIP profile. If the entry also
contains the mobile controller’s IMSI, it will appear before the IP addresses.
The following entry shows the
route.cfg configuration file changed according to the formula:
Example: The following CDR entry includes IP addresses for signaling and voice data, audio codec and
frame size.
...
Subscriber00=TRANSPARENT ROUTER ALARM NODE[0000]
...
C1,25.11.09-10:16:20,25.11.09-10:16:27,[0000:01]9,[0006:01]111,,,,,0102,7,1f,0,,3663,10
C1,25.11.09-10:35:16,25.11.09-10:35:26,9,111,123456789123451,,,,0102,10,1f,0,3,38922,14
...
Subscriber04=TRANSPARENT ROUTER UMTS[0000,00000,<SMSC>,1,1,1,SIM4,IMSI] CHADDR ALARM NEXT
Subscriber05=TRANSPARENT ROUTER UMTS[0000,00000,<SMSC>,1,1,1,SIM4,IMSI] CHADDR ALARM NEXT
Subscriber06=TRANSPARENT ROUTER UMTS[0000,00000,<SMSC>,1,1,1,SIM4,IMSI] CHADDR ALARM NEXT
Subscriber07=TRANSPARENT ROUTER UMTS[0000,00000,<SMSC>,1,1,1,SIM4,IMSI] CHADDR ALARM NEXT
...
[Voip=Default]
VoipDirection=IO
VoipPeerAddress=192.168.0.2
VoipIpMask=0xffffffff
VoipCompression=g729 g711a t38
VoipMaxChan=30
VoipSilenceSuppression=Yes
VoipSignalling=0
VoipTxM=4
VoipIPLogging=Yes
C1,24.11.09-16:52:20,24.11.09-16:52:22,401419,9777,,172.20.25.103:172.20.25.103,G711a,20,0101,2,10,0,,34193,11
