CONFIGURATION FILES
CHAPTER 5
65
ECOTEL 3G 16.1. Revised: 1 March 2011.
Optional Mobile Parameters
In addition to the usual parameters, you can enter the following optional mobile parameters. Separate each pa-
rameter with a comma.
<loudGSM>
Defines the volume level for the mobile line. The values 0 to 3 are possible. 0 is loudest
and 3 is the least loud.
Activating echo cancellation:
Depending on the base station (BTS) one of three algorithms will work for this feature.
The algorithms must be tested during activation to determine which one fits the base
station type.
The following values are added to the volume setting:
- 16 -> algorithm 1
- 32 -> algorithm 3
- 48 -> algorithm 6
EXAMPLE 1: If the volume level is set at 1, and algorithm 1 is used for echo cancellation,
the configuration for <loudGSM> is 17:
Subscriber00=… UMTS[0000,00000,+000000,1,17,1,SIM4] …
EXAMPLE 2: If the volume level is set at 2, and algorithm 6 is used for echo cancellation,
the configuration for <loudGSM> is 50:
Subscriber00=… UMTS[0000,00000,+000000,1,50,1,SIM4] …
<loudPCM>
Defines the volume level to the fixed network. The values 0 to 7 are possible. 7 is loudest
and 0 is the least loud.
SIM<x>
The number entered for <x> refers to the number of slots read out to activate the mobile
ports.
NOTE: This parameter cannot be used in combination with
SIMS.
Table 5.17 Optional Mobile Parameters in pabx.cfg
Optional Mobile Parameters
SIMS
Define this keyword to connect the system to a vGATE.
<sim> must be set to 1 in the appropriate mobile
controller
Subscriber line.
NOTE: This parameter cannot be used with the parameters
SIM4.
EXAMPLE:
Subscriber00=TRANSPARENT ROUTER UMTS[0000,00000,<SMSC>,1,1,1,SIMS]
Table 5.16 Required Mobile Parameters in pabx.cfg (continued)
Subscriber<port>=<type>
[<pin>,<lain>,<SMSC>,<sim>,<loudGSM>,<loudPCM>,SIM<x>,...]
